Kwikstage Two Board Hopup Bracket

The Two Board Hop-Up Bracket is a key accessory in the Kwikstage scaffolding system, used to create an additional work platform by supporting two scaffold boards. Mounted on the inner face of the scaffold structure, it provides elevated access to wall areas, making it ideal for plastering, bricklaying, rendering, and finishing work.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button


Overview


The Kwikstage Two Board Hopup Bracket is a practical solution for creating extended work platforms on scaffolding systems, designed to support two standard scaffold boards. Constructed from hot-rolled mild steel with a black painted finish, this bracket offers reliable performance at a cost-effective price point. The simple L-shaped design features open slots for board insertion and welded tabs for secure attachment to ledgers, ensuring quick installation in high-paced construction environments.


Features


Economical Design: Uncoated steel with protective paint (50μm thickness) balances affordability with moderate corrosion resistance for short-term projects.

Dual Board Capacity: Holds two 38x225mm timber or composite boards, with 250mm platform projection from the main frame.

Tool-Free Assembly: Boards slot into place and are secured by gravity, ideal for temporary setups where speed is prioritized.

Basic Load Rating: Supports 200kg distributed load, suitable for light-duty tasks like painting and inspections.


Application


Ideal for budget-conscious projects requiring temporary platform extensions, this bracket is used in:

1. Residential exterior renovations, such as siding replacement and window painting

2. Small-scale industrial maintenance, accessing machinery at height

3. Event staging for temporary lighting and sound platforms

4. Warehouse shelf installation, providing safe access for stock placement.


FAQ


Q: How long does the paint finish last outdoors?

A: Approximately 12-18 months in moderate climates. Reapply paint annually for extended use.

Q: Can it be modified for single-board use?

A: Yes, though load capacity reduces to 100kg. Always use both slots for optimal stability.

Q: What is the weight of the bracket?

A: 1.8kg per unit, lightweight enough for one-handed handling during installation.

Q: Does it require additional bracing for the extended platform?

A: Yes, install diagonal braces every 3m to prevent ledger deflection under load.
